Details
Fully loaded bike-packing, fast and light off-road adventures, gravel and CX racing… or simply exploring your favorite tracks and trails. The Headlands is a high-tech, high-spec carbon fiber gravel and adventure bike that’s made to be lightning-fast, confidence-inspiring and super comfortable on all surfaces.
We’ve taken our own unidirectional carbon fiber frame, added mountain bike-inspired geometry, loads of tire clearance and a whole heap of mounting points for gear and fenders to create a super versatile, super capable all-terrain dart of a bike. Go 700c with room for up to 45mm tires or 650b up to 47mm.
The Headlands 2 is our no-compromise, top-spec, top-performance gravel and adventure bike.
Gravel-specific SRAM Apex 12-speed drivetrain, 44mm Vee Tire Co tires and Marin wheels and finishing kit all add up to a whole mountain of fun and adventure. Last but not least, we’ve added a TranzX dropper seat post to really push you and your Headlands’ limits on the trails.
SIZE | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
---|---|---|---|---|---|---|
A- STACK (mm) | 550.3 | 565.7 | 581.8 | 600.8 | 619.7 | 638.7 |
B- REACH (mm) | 370 | 372.8 | 372.7 | 386.4 | 411.4 | 425.8 |
C- HEAD TUBE ANGLE (°) | 70.5° | 71° | 71.5° | 71.5° | 71.5° | 71.5° |
D- HEAD TUBE LENGTH (mm) | 120 | 135 | 150 | 170 | 190 | 210 |
E- SEAT TUBE ANGLE (°) | 74.5° | 74° | 73.5° | 73.5° | 73.5° | 73.5° |
F- SEAT TUBE LENGTH (mm) | 440 | 470 | 490 | 510 | 530 | 550 |
G- TOP TUBE EFFECTIVE (mm) | 522 | 535 | 545 | 565 | 595 | 615 |
H- BB HEIGHT (mm) | 283.5 | 272 | 272 | 272 | 272 | 272 |
I- BB DROP (mm) | 76 | 76 | 76 | 76 | 76 | 76 |
J- CHAIN STAY (mm) | 420 | 420 | 420 | 420 | 420 | 420 |
K- WHEEL BASE (mm) | 1010.2 | 1007.4 | 1007.7 | 1028.5 | 1059.2 | 1079.9 |
L- STAND OVER HEIGHT (mm) | 711 | 725 | 741 | 758 | 775 | 792 |
M- FORK OFFSET (mm) | 50 | 50 | 50 | 50 | 50 | 50 |
SEATPOST DIAMETER (mm) | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
HANDLEBAR WIDTH (mm) | 420 | 420 | 420 | 440 | 440 | 440 |
STEM LENGTH (mm) | 60 | 60 | 60 | 60 | 70 | 70 |
CRANK LENGTH (mm) | 170 | 170 | 175 | 175 | 175 | 175 |
SIZE | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
---|---|---|---|---|---|---|
Rider Height (In) | 4'11 to 5'3'' | 5'3" - 5'6" | 5'6" - 5'9" | 5'9" - 6'0" | 6'0" - 6'2" | 6'2" - 6'4" |
Specs
Frame | Unidirectional Carbon Beyond Road Platform, 1x Drivetrain Specific, 700c x 45mm/650B x 50mm Compatible, Flat Mount Disc, 142x12mm Thru-Axle, Internal Dropper Post Routing, Internal Housing Routing, Mudguard and Rear Carrier Mounting, Plentiful Gear Mounts |
---|---|
Fork | Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets |
Wheels | Marin Aluminum Double Wall, 21mm Inner, 21mm Tall, Disc Specific, Tubeless Compatible |
Hubs | Forged Aluminum Alloy, Disc, 28H |
Tires | Vee Tire Co., G-Sport, 700cx44, Tubeless Compatible |
Bottom Bracket | SRAM DUB BSA |
Crankset | SRAM Apex 1, 40T |
Shifters | SRAM Apex 1 1x12-Speed |
Rear Derailleur | SRAM Apex 1 12-Speed |
Cassette/Freewheel | SRAM CS-XG-1275, 10-52T |
Chain | SRAM NX |
Brakes | SRAM Apex 1 Flat-Mount Hydraulic Disc, 160mm Rotor |
Brake Levers | SRAM Apex 1 Hydraulic Disc |
Handlebars | Marin Butted Alloy, Compact 16º Flared Drop |
Tape/Grips | Marin Shock Absorbing Tape |
Stem | Marin 3D Forged Alloy |
Headset | FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2” |
Seatpost | TranzX YSP38J, Size 49-54 70mm, Size 56-60 105mm Travel, 27.2mm |
Saddle | Marin Beyond Road Concept Elite |
* Subject to change without notice.
